Engine
ENGINE TYPE
Single cylinder, 4 stroke, 4 valve, liquid cooled
DISPLACEMENT
125
BORE X STROKE
54,0 x 54,5 mm
COMPRESSION RATION
12,0:1
RATED OUTPUT
15hp / 11,0 kW @ 9500 rpm
MAX. TORQUE
12,1 Nm @ 7000 rpm
LUBRICATION
Forced wet sump
FUEL SUPPL
Electronic fuel injection with throttle body ø 28 mm
EXHAUST SYSTEM
With catalytic converter and double oxygen sensors
CERTIFICATION
Other
ELECTRICAL SYSTEM
EFI
CLUTCH
Wet multi-plate
GEARBOX
6 Speed
FINAL DRIVE
Chain
IGNITION
BOSCHTM MOTRONIC MES 8.0
COOLING SYSTEM
Liquid-cooled
BATTERY
12V11.2Ah
SPARK PLUG
NGK CR8E
STARTING
Electric
Chassis
FRAME
Trellis frame in steel tubes
FRONT SUSPENSION
41 mm upside-down forks full adjustable in spring preload and hydraulic brake rebound and compression
FRONT SUSPENSION STROKE
180 mm
FRONT BRAKE
Single floating disks 280 mm with 4 pistons calliper with and ABS
REAR SUSPENSION
Rear swing arm in steel, shock absorber with progressive link, adjustable in spring preload and hydraulic brake rebound
REAR SUSPENSION STROKE
180 mm
REAR BRAKE
Single disc 240 mm with floating calliper single piston and ABS
FRONT RIM TYPE
Spoked wheel with Aluminum hub and rim
REAR RIM TYPE
Spoked wheel with Aluminum hub and rim
REAR RIM DIMENSION
17
FRONT TYRE
90/90 - 19 M/C
REAR TYRE
120/90 - 17 M/C
HEADLIGHT LAMP
LED
TAILLIGHT LAMP
LED
Dimensions
LENGTH
2090 mm
WIDTH
910 mm
HEIGHT
1210 mm
GROUND CLEARANCE
233 mm
UNLADEN WEIGHT
144 kg
USABLE TANK VOLUME
12 lt
RESERVE
1.5 lt
WHEELBASE
1430 mm
SEAT HEIGHT
860 mm
